Vibrating Screen Manufacturer | Propel Industries

WATCH VIDEO

TECHNICAL DATA

SERIES	UNITS	MVS 1540	MVS 1845	Dual Slope 1860	MVS 2060	MVS 2561	MVS 1850
Screen Size (W x L)	mm (inch)	1500 x 4000 (59.1 x 157.5)	1800 x 4500 (71.0 x 177.2)	1850 x 6000 (72.9 x 236.2)	2000 x 6000 (78.7 x 236.2)	2500 x 6100 (98.4 x 240.2)	1800 x 5000 (70.9 x 196.9)
Screening Area	sq.m	6.0	8.1	11.1	12.0	15.1	8.91
*Capacity	TPH	300	400	600	650	800	200
Number of Decks		2 / 3 / 4	2 / 3 / 4	4	2 / 3 / 4	3 / 4	1
Mounting Type (optional)		Skid	Skid	Skid	Skid	Skid	Skid
Screen Position		Inclined	Inclined	Inclined	Inclined	Inclined	Inclined
Type of Motion		Circular	Circular	Elliptical	Circular	Circular	Circular
Motor Power	kW (hp)	15 (20)	15 (20)	15 (20)	22 (30)	30 (40)	2X5 (6.7)
Weight	kg (Ton)	3500 / 4300 / 5100 (3.5 /4.3 / 5.1)	4000 / 4800 / 5400 (4.0/ 4.8 / 5.4)	7600 (7.6)	6600 / 7500 / 8700 (6.6/ 7.5 / 8.7)	12500 / 14500 (12.5 / 14.5)	4000 (4.0)

*Details may vary based on application
**Motor Power for MVS 1540 single deck
Note: All the above technical details may vary at any time during engineering process & design development
