6x4 470 MEV-ROCK |
8X4 470 HEV-ROCK |
8X4 470 HEV-COAL |
| DIMENSIONS |
| Wheel Base |
4300 mm |
5900 mm |
6215 mm |
| Overall Size (L X W X H) |
8275 x 2800 x 3650 mm |
9875 x 2800 x 3700 mm |
10190 x 2800 x 3700 mm |
| Min. Ground Clearance,
Angle Of Approach |
265 mm |
305 mm |
265 mm |
| Angle of Approach |
24° |
25° |
24° |
| Body ( Rock Body With Hardox / WRS) (cum) |
18 Cum |
25.5(SAE HEAP) |
33 (BOX U-BODY) |
| KERB Weight(kg) |
16400 |
21400 |
19500 |
| Gross Vehicle Weigh |
45000 kg |
60000 kg |
55000kg |
| MotorType |
PMSM |
PMSM |
PMSM |
| MaxPower |
350kW |
350kW |
350kW |
| MaxTorque |
2800 Nm |
2800 Nm |
2800 Nm |
| Transmission(Clutch-less) |
7speed EMT |
7speed EMT |
7speed EMT |
|
| Front Suspension |
1x9.5T Parabolic Leaf Spring with Shock Absorber and Anti-roll Bar |
2x9.5T Parabolic Leaf Spring with Shock Absorber and Anti-roll Bar |
2x9.5T Parabolic Leaf Spring with Shock Absorber and Anti-roll Bar |
| Rear Suspension |
37T Inverted Bogie Semi Elliptical |
37T Uprated Inverted Bogie Semi Elliptical |
37T Uprated Inverted Bogie Semi Elliptical |
| Axles |
| FrontAxle |
Steerable,Theavy duty I Beam |
Steerable,Theavy duty I Beam |
Steerable,Theavy duty I Beam |
| Rear Axle |
Heavy duty Tandem, Hub Reduction cast axle |
Heavy duty Tandem, Hub Reduction cast axle |
Heavy duty Tandem, Hub Reduction cast axle |
| Rear Axle Ratio |
7.63 |
7.63 |
7.63 |
| Chassis Frame |
Ladder construction ,C-channel with full flitch reinforcement |
Ladder construction,C-channelwith full flitch reinforcement |
Ladder construction,C-channelwith full flitch reinforcement |
| Tyres |
12x20 Mining tyre |
12x24 Mining tyre |
12x20 Mining tyre |
| Steering |
Hydraulic integral power steering, TAT(Tilt and Telescopic) |
Hydraulic integral power steering, TAT(Tilt and Telescopic) |
Hydraulic integral power steering, TAT(Tilt and Telescopic) |
| Brakes |
| ServiceBrakes |
Dual line air brakes with ABS |
Dual line air brakes with ABS |
Dual line air brakes with ABS |
| Parking Brakes |
Pneumatic Hand Control Valve |
Pneumatic Hand Control Valve |
Pneumatic Hand Control Valve |
| HillStartAssist |
Integrated with service brake |
Integrated with service brake |
Integrated with service brake |
| Cabin |
SleeperCabin, Tiltable | KeylessEntry | Four Point Suspension | Power Windows |Air Suspended Driver Seat
|
SleeperCabin, Tiltable | KeylessEntry | Four Point Suspension | Power Windows |Air Suspended Driver Seat
|
SleeperCabin, Tiltable | KeylessEntry | Four Point Suspension | Power Windows |Air Suspended Driver Seat
|
| Main Battery Packs |
CellChemistry : Li-on Pack capacity(kWh):171/256
|
CellChemistry:Li-on Pack capacity(kWh):256/385
|
CellChemistry:Li-on Pack capacity(kWh):256/385
|
| Performance |
Maximum Speed(km/h):40-locked Turning Circle Diameter(m): 16.5| Gradeability : >30% |
Maximum Speed(km/h):40-locked Turning Circle Diameter(m) : 22| Gradeability : >30% |
Maximum Speed(km/h):40-locked Turning Circle Diameter(m) : 23.6 | Gradeability : >30% |
| ToolKit |
Standard Tool Kit, First aid Kit, Warning Triangle, and Fire Extinguisher
|
Standard Tool Kit, First aid Kit, Warning Triangle, and Fire Extinguisher
|
Standard Tool Kit, First aid Kit, Warning Triangle, and Fire Extinguisher
|
|
*DGMS Optional
**On road variant under certification
|
*DGMS Optional
**On road variant under certification |
*DGMS Optional
**On road variant under certification |
